fabric expansion joint customised for use in Various Auxiliary Systems (VA)

BELMAN-VA

The Belman VA type Fabric Expansion Joints are designed to use specially in Various Auxiliary systems (VA). It is a custom made Fabric Expansion Joints solution (either closed or special requirements as open belt for joining on-site) with bellows designed to solve the movement absorption in the application as well as meet requirements made by the gap in the pipeline.

It is a single- or multilayer design that safely absorbs movements caused by thermal expansions in pipelines & duct systems and with the possibility to be designed to accommodate misalignments on request.

Applicable for Chemical industry, Oil & Gas, Power Plant, Pulp & Paper, Steel plants, Process industry, Flue Gas Systems, Boilers & Stacks and many more.

Design range within Fabric Expansion Joint type AI

Belman VA Fabric Expansion Joints can be designed within the range:

Belman_India_Icon_250x250px_Size of components

DIMENSIONS:
All sizes and shapes

Belman_India_Icon_250x250px_High Preasure_1

PRESSURE:
Up to +/-25,000 Pa (+/- 2500 mmWg)
Special constructions are
available on request

TEMPERATURE:
Up to 200°C, minimum
temperature -50°C

MATERIALS:

Flexible parts: Glass fabric, Wool material, PTFE, Silicones, Wire mesh amongst others
Connection ends & Hardware: As per client request

TESTS:

Visual test, dimension check
or as per client specifications.

Belman_India_Icon_250x250px_Design codes

CERTIFICATES:

On request certificates for steel
parts can be supplied.

Belman-VA for Various Auxiliary Systems

PRODUCT RANGE

VA-RR-EP18-N

Temperature: 120°C
Pressure limit: +/- 20000 Pa
Media: Various (Dry)
Comment: Only supplied as closed

VA-GR-EPGL-S

Temperature: 120°C
Pressure limit: +/- 20000 Pa
Media: Various (Dry)
Comment: Only supplied as closed

VA-RR-EPKE-N

Temperature: 120°C
Pressure limit: +/- 60000 Pa (surge pressure)
Media: Various (Dry and wet)
Comment: Only supplied as closed

VA-RR-EP60-N

Temperature: 120°C
Pressure limit: +/- 25000 Pa
Media: Various (Dry and wet)
Comment: Only supplied as closed

VA-GS-ALUS-S

Temperature: 200°C
Pressure limit: +/- 20000 Pa
Media: Various (Dry and wet)

VA-AA-PA06-S

Temperature: 70°C
Pressure limit: +/- 15000 Pa
Media: Various (Dry and wet)
Comment: Only supplied as closed

VA-AA-PA15-S

Temperature: 70°C
Pressure limit: +/- 25000 Pa
Media: Various (Dry and wet)
Comment: Only supplied as closed

BELMAN-AI

TECHNICAL DESCRIPTION

DESIGN FEATURES

Multilayer Fabric Expansion Joint
For dry operation (non-aggressive media)
Customized to application and project
Absorbing multiplane movements simultaneously

APPLICATIONS

Oil & gas
Power plant
Pulp & Paper
Cement industry
Steel plants
Process industry
Flue gas systems
Boilers and stacks
…and many more

SPECIFICATIONS

Following are the operating features and movement absorbtion abilities of the Belman VA type Fabric Expansion Joints :

OPERATING FEATURES

Temperature range: Up to +200°C (minimum temperature: -50°C)
Pressure range: Up to +/- 25,000 Pa (+/- 2500 mmWg)
Non-aggressive (Dry and wet)

MOVEMENTS

Absorbs movements in multiple directions (several planes) simultaneously
absorb large movements within short built-in lengths
(Due to the multilayer construction).

Belman-VA for Various Auxiliary Systems

INFORMATION & TOOLS



Data Sheet

Download the data sheet for Belman-VA for Various Auxiliary systems. It contains all the information of,

technical data, product features, design features, applicability,
and many more

DOWNLOAD



check list

Download the check list for Fabric Expansion Joints. It contains,

everything you need to check when it comes to Fabric Expansion Joints.

DOWNLOAD



inquiry sheet

Download the inquiry sheet for Belman-VA for Various Auxiliary systems. To get the exclusive suport on Fabric Expansion Joints,

Fill the online inquiry sheet and send it back to Belman.

DOWNLOAD

CONNECTION ENDS & HARDWARE

Fabric Expansion Joint type Belman-VA is delivered as a customized design (either closed or as open belt for joining on-site) with bellows designed to solve the movementabsorption in the application as well as meeting additional requirements made by the gap in the pipeline.

Belman-VA is supplied as a stand-alone Fabric Expansion Joint (with parallel or vertical fixing flange arrangement) that may be supplied with customized connection ends and including hardware, but not limited to:

Complete units (flanged or with welding ends)
With loose flanges
With clamping bands
Special transport fixtures
Flow liners / inner sleeves
Pre-setting construction

ADVANTAGES

Minimum reaction forces
Excellent movement absorption and flexibility
Extensive application range
Good vibration resistance depending on design and materials
Can accommodate misalignments and a large amount of lateral offset (special design may be required and needs to be specified at inquiry stage)
